Home > Hastelloy C22 Stud Bolts
Request For Our Latest Prices On Hastelloy C22 Stud Bolts in Doha, Qatar!
Murad Fasteners has earned a solid reputation as a reliable manufacturer and supplier of Hastelloy C22 Stud Bolts in Doha, Qatar. They specialize in providing high-performance fastening solutions tailored for industries that operate in tough, corrosive environments. These stud bolts are crafted with precision from top-quality Hastelloy C22 alloy, which guarantees outstanding corrosion resistance, mechanical strength, and impressive durability. Murad Fasteners offers a variety of sizes, grades, and finishes to cater to the diverse needs of different industries. Renowned for their dependability and strong performance, Hastelloy C22 Stud Bolts are perfect for applications in chemical, petrochemical, marine, and high-temperature settings where secure fastening is essential.
The composition of Hastelloy C22 Stud Bolts includes primarily nickel, chromium, molybdenum, tungsten, along with trace amounts of iron and cobalt. This unique blend provides them with remarkable resistance to pitting, crevice corrosion, and both oxidizing and reducing chemicals. They boast high tensile and yield strength, excellent toughness, and superior mechanical stability, even in extreme conditions. These bolts maintain their dimensional accuracy and structural integrity, even when faced with high temperatures, aggressive chemicals, and significant mechanical stress, ensuring reliable performance in critical industrial assemblies.
| Specifications | ASTM B574 / ASME SB574 |
|---|---|
| Fasteners size | Bolt / Screw Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size : M1.6 – M12 Self Tapping Screw Size : No.2 – No. 14 |
| Fasteners Length | 3 mm to 200 mm |
| Fastener Threads | UNF, BSW, BSF, METRIC, UNC or as required |
| Standard of High Nickel Alloy Fasteners | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Surface Coating | Ptfe Coated High Nickel Alloy Fasteners Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Fasteners Finishing | High Nickel Alloy : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), High Nickel Alloy, Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide. |
| Grade | C | Mn | Si | Co | S | Ni | Cr | Fe | Mo | W | V | P |
| Hastelloy Fasteners | 0.010 max | 1.0 max | 0.08 max | 2.5 max | 0.03 max | Bal | 14.5 – 16.5 | 4 – 7 | 15 – 17 | 3 – 4.5 | 0.35 max | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy Fasteners | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
Hastelloy C22 Stud Bolts find extensive use in various sectors, including chemical processing, petrochemical plants, oil and gas, marine, and power generation. They’re commonly utilized in reactors, pressure vessels, pipelines, heat exchangers, and other assemblies that are exposed to harsh, corrosive, or high-temperature environments. Their exceptional chemical resistance and mechanical strength guarantee secure fastening, a longer service life, and dependable performance in demanding industrial operations where safety, durability, and operational efficiency are of utmost importance.
At Murad Fasteners, our Hastelloy C22 Stud Bolts are meticulously packaged to ensure maximum protection and ease of handling. Each stud bolt is securely wrapped in protective material to prevent damage during transit. The bolts are then placed in durable, clearly labeled boxes, facilitating easy identification and inventory management. For bulk orders, we use sturdy pallets and shrink-wrap to maintain the integrity of the packaging and safeguard the product until it reaches its destination.
Murad Fasteners is a leading manufacturer and supplier of high-quality fasteners in Doha, Qatar, with over 8 years of experience serving global industries.
